Technical Details

• Package / Case 6-TSSOP, SC-88, SOT-363
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 360mOhm (Typ)
• -3db Bandwidth 80MHz
• Supplier Device Package SC-88 (SC-70-6)
• Voltage - Supply, Single (V+) 1.65V ~ 4.3V
• Charge Injection 6pC
• Switch Circuit SPST - NO
• Multiplexer/Demultiplexer Circuit 1:1
• Switch Time (Ton, Toff) (Max) 55ns, 65ns
• Channel Capacitance (CS(off), CD(off)) 38pF
• Current - Leakage (IS(off)) (Max) 10nA
• Number of Circuits 1
